Advanced Protection for Rotating Machinery Assets
Techzeel MotionCore Speed Measurement Module – MC-200 Series is a high-performance XM-220 dual-speed module designed for critical machinery protection and precision rotational speed monitoring.
Key Configurations
94mm x 97mm x 94mm compact DIN-rail mounting.
-20°C to 65°C for harsh industrial environments.
300 mA maximum at 24V DC supply voltage.
2.0 G at 10 to 500 Hz frequency.
1.0 to 1,200,000 RPM measuring speed and acceleration.
120 kΩ minimum for eddy current and TTL inputs.
250V continuous rating between the relay and other circuits.
DeviceNet connectivity for real-time digital data transmission.
The Benefits You Enjoy
Automatic sensor switching occurs upon detection of transducer faults.
Supports multiple sensors, including magnetic pickups and optical tachometers.
On-board DPDT relay enables localized hardware-based emergency machine shutdowns.
